sv2575 SV2575 2575
ENGINE: | Kohler KDI 2504 TCR |
POWER* : | 55,4 kW @2600 rpm |
MAX. TORQUE: | 300 Nm @1500 rpm |
NOISE LEVEL** : | 74 dB(A) |
WEIGHT*** : | 525 kg |
DIMENSIONS (LxWxH) : | 120 x 90 x 94 cm |
EMISSIONS COMPLIANCE: | Stage III B - Tier 4 Final |
FUEL CONSUMPTION: | 16 l/h |
* POWER: ISO 3046 IFN
** NOISE: taken at 7 meters @2200 rpm without load
*** WEIGHT: oil and cooling liquid included
STANDARD EQUIPMENT
- SAE 4 - 7” ½ flanging
- Accelerator/potentiometer knob
- Control panel with tachometer and hour meter
- Emergency stop button
- 12 V electric start
- Exhaust silencer
- Electric fuel pump
- External OBD port
OPTIONAL ACCESSORIES
- Hydraulic pump adapter on 1st PTO
- Hydraulic pump adapter on 3rd PTO
- Cylindrical shaft extensions
- Industrial lever clutches
ENGINE: Kohler KDI 2504 TCR
- Cylinders: 4
- Displacement (cm3): 2482
- Bore (mm): 88
- Stroke (mm): 102
- Injection system: DI
- Four stroke diesel engine with in-line cylinders
- Liquid cooling
- 4 valves per cylinder
- Crankcase camshaft, timing gear
- Pushrods rocker arms timing with hydraulic valve tappets
- Cast iron crankcase with bed plate
- Cast iron cylinder head
- Engine electronic management
- Close-circuit crankcase breather
- Direct injection - High pressure common rail (2000 bar)
- Wastegate turbocharger
- Charge - air cooling
